MikroTik RB2011UiAS-RM


MikroTik RB2011UiAS-RM

Product Specifications:

Product code RB2011UiAS-RM
Architecture MIPSBE
CPU AR9344
CPU core count 1
CPU nominal frequency 600 MHz
Dimensions 214mm x 86mm for PCB
License level 5
Operating System RouterOS
Size of RAM 128 MB
Storage size 128 MB
Storage type NAND
Tested ambient temperature -35C to +65C
Suggested price $119.00


Max Power consumption 6W
PoE in Passive PoE
PoE out Passive PoE
PoE in input Voltage 8-30 V
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 8-30 V


10/100 Ethernet ports 5
10/100/1000 Ethernet ports 5


SFP ports 1


Serial port RJ45
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 2


PCB temperature monitor Yes
Voltage Monitor Yes



MikroTik RB2011UiAS-RM

Shop for MikroTik RB2011UiAS-RM in Nairobi from Starmount mikrotik dealers


RouterBoard 2011UiAS-RM

The RouterBoard 2011UiAS-RM can be considered a landmark especially if it’s compared with the other router boards in the series like RouterBoard 2011UAS. It is not only affordable but it’s loaded with various handy and nifty features.

Easy and Fast Connectivity

The RouterBoard 2011 UAS-RM now has 5 LAN ports along with 5 fast Ethernet ports. What’s more, you can make use of an RJ45 connector for the serial port and a microUSB port. In other words, you can design different types of network schemes with this router board. You can go for something simple to something more intricate or complex, serving various network users and sharing bigger content without compromising the speed and performance of the Internet.

Quick Configuration

Along with the power supply, the RouterBoard 2011UiAS-RM’s package includes a rack mount enclosure. There’s also an SFP cage, so the only thing to think about is the module. There’s n LCD panel that’s touch screen so you won’t have a hard time configuring the device. It also has an auto-MDI/X capability, which means it adjusts itself depending on what cable wires you attach. There’s no need to guess or go through trial and error when it comes to cables.

Great Support

The router board is fitted with the Level 5 RouterOS, which gives you a month of excellent initial configuration support from MikroTik. You can also set up the router board into a wireless access point and bridge and enjoy 500 PPPoE, L2TP, and PPTP tunnels, as well as unlimited OVPN and VLAN interface support. Other benefits include 500 hotspot active users, support for RADIUS client, unlimited queues, unlimited KVM guests, 50 user manager active sessions, and support for RIP, BGP, and OSPF protocols. It is equipped with 128MB RAM, NAND Flash, and Atheros AR9344 running on 600MHz.

PoE output

There is PoE output function for port #10 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.
