MikroTik RB2011UiAS-RM
Shop for MikroTik RB2011UiAS-RM in Nairobi from Starmount mikrotik dealers
DESCRIPTION
The RouterBoard 2011UiAS-RM marks a big step forward compared to other router boards in the same series like the RouterBoard 2011UAS. It gives you an affordable option while still offering many useful and smart features.
Easy and Fast Connectivity
The RouterBoard 2011 UAS-RM now has 5 LAN ports along with 5 fast Ethernet ports. What’s more, you can make use of an RJ45 connector for the serial port and a microUSB port. In other words, you can design different types of network schemes with this router board. You can go for something simple to something more intricate or complex, serving various network users and sharing bigger content without compromising the speed and performance of the Internet.
Quick Configuration
Along with the power supply, the MikroTik RB2011UiAS-RM package includes a rack mount enclosure. There’s also an SFP cage, so the only thing to think about is the module. There’s n LCD panel that’s touch screen so you won’t have a hard time configuring the device. It also has an auto-MDI/X capability, which means it adjusts itself depending on what cable wires you attach. There’s no need to guess or go through trial and error when it comes to cables.
Great Support
The router board is fitted with the Level 5 RouterOS, which gives you a month of excellent initial configuration support from MikroTik. You can also set up the router board into a wireless access point and bridge and enjoy 500 PPPoE, L2TP, and PPTP tunnels, as well as unlimited OVPN and VLAN interface support. Other benefits include 500 hotspot active users, support for RADIUS client, unlimited queues, unlimited KVM guests, 50 user manager active sessions, and support for RIP, BGP, and OSPF protocols. It is equipped with 128MB RAM, NAND Flash, and Atheros AR9344 running on 600MHz.
There is PoE output function for port #10 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.
Product Specifications:
| DETAILS | |
| Product code | RB2011UiAS-RM |
| Architecture | MIPSBE |
| CPU | AR9344 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Dimensions | 214mm x 86mm for PCB |
| License level | 5 |
| Operating System | RouterOS |
| Size of RAM | 128 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Tested ambient temperature | -35C to +65C |
| Suggested price | $119.00 |
Powering
| DETAILS | |
| Max Power consumption | 6W |
| PoE in | Passive PoE |
| PoE out | Passive PoE |
| PoE in input Voltage | 8-30 V |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 8-30 V |
Ethernet
| DETAILS | |
| 10/100 Ethernet ports | 5 |
| 10/100/1000 Ethernet ports | 5 |
Fiber
| DETAILS | |
| SFP DDMI | Yes |
| SFP ports | 1 |
Peripherals
| DETAILS | |
| Serial port | RJ45 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 2 |
Other
| DETAILS | |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
